I'm Jake von Slatt, a maker, tinkerer, fabricator, and all around techno dilettante living and creating just outside of Boston, Massachusetts. I'm interested in the blending of 19th century aesthetics and technology with the modern world and showcasing projects of that ilk here on SteampunkWorkshop.com. While I eschew the temptation to rigidly define the term "Steampunk," I do know that it has something to do with the intersection of technology and romance. More after the break

Email: jake@vonslatt.com
YouTube Channel: VonSlatt
Twitter: vonslatt

Cuisinart Top Interlock Repair

Articles:

Repaired Cuisinart interlock tabWe got our first Cuisinart in 1982. It served us well for more than a decade so when it finally gave up the ghost we purchased another one. We were dismayed to find that the new Cuisinart Custom 14 had changed the interlock on the mixing bowl and top. There was now an additional tab so that the large plunger had to be in place and you were limited to the 2 inch diameter hole for feeding to process while the machine was running. It was annoying but we lived with it. But the plastic tab on this complicated interlock eventually broke. So we decided to design a 3-D printable replacement part that would return the operation to the way the old-style Cuisinart worked.

. . .

Nightmare Blues - New from Aaron J. Shay

Articles:

Friend of SPWS Aaron J. Shay has released a new music video for his banjo-rock barnstormer "Nightmare Blues" just in time for Halloween!

Hexayurt for Burning Man

Hexayurt for Burning ManMy family and I are headed to Burning Man this year.

I have been twice in the past and have always stayed in a tent. I was reasonably comfortable, however sleeping late was problematic. As soon as the sun rose over the RV I had pitched my tent next to, it simply got too hot to continue sleeping.

So this year I built a Hexayurt to stay in. The Hexayurt is a structure originally developed for disaster response. It's a hexagonal hut built out of foam insulating panels and super strong bi-filament fiberglass reinforced tape. The particular design I chose is made from 12  4' x 8' panels. Six of the panels are cut diagonally and connected together to form six triangles. These triangles become the roof. The other six panels are laid on their side and set out in a hexagon and make the walls of the Hexayurt. The foil surface of the panels and their insulating qualities make this an ideal structure for desert camping.

I won't go into too much detail concerning the construction of my Hexayurt. If you are interested, you should go to Hexayurt.com the repository for all such information

My Hexayurt will be shipped to the playa on the Boston burning truck. We'll be flying in at the beginning of the event and taking the bus from Reno to Black Rock city. However, the Burner Express stop where we'll arrive is about half a mile from the place where the Hexayurt will be deposited. Keep on reading to see how I'll deal with that situation.

Hexayurt Swamp Cooler for Burning Man!

Articles:

We're headed to Burning Man this year! I am in the process of building a Hexayurt for us to stay in on the playa. To keep it cool I'm going to build a solar powered swamp cooler. These are a few of the components that I've gathered so far. The whole build process will be here in the upcoming weeks.

UPDATED: Click though for full story!



Quickest Way to Clone Windows (and Windows Server) Disk with GPartEd

A quick tech note from the day job some of you might find useful.

GPartEd is a fantastic free tool for copying and resizing disk partitions, but cloning an entire Windows disk often requires tweaking boot sectors and records after the partitions are copied and this is not always easy or intuitive. The following is a simple method to clone a Windows disk quickly without all the messing around with boot sector issues.  I just used this on Windows Server 2008 but it should work on Windows Server 2012, Windows 7 and Windows 8.


. . .

DIY Vibratory Tumbler

When I built the Girl Genius Radio Theater Microphone I had some brass plates water-jet cut and I bought a vibratory tumbler to polish them. The tumbler came from Eastwood and while it did a very nice job on the parts for the microphone, it failed shortly thereafter. When I took it apart I found that the bearings in the motor were shot, they had been destroyed by the vibration.

So I built a sturdier, more powerful tumbler myself.

SPWS Youtube Channel

Hi folks! I'm going to be making a concerted effort to post more videos of my projects. I'll continue with the step-by-step photos and write-ups but I'm going to augment those with video overviews and to that end I've acquired a new video camera and set up a Youtube Channel.  Subscribe to The Steampunk Workshop Youtube Channel Now!

New(ish) Sewing Machine into an Old Table

Some time ago I found an antique White sewing machine at the dump. At first glance it looked to be in really good shape but upon closer inspection it was clear that it had sat in a damp environment for a long, long time. The hide glue on most of the wooded parts was no longer holding them together, the machine itself had rust inside and out, and the cast iron treadle frame was broken in two places. The machine sat in the corner of my office for a couple of years until I found a portable sewing machine from the 1970's that was almost unused and worked perfectly. That's when I decide to combine the two and make this a useful piece of furniture once again.

. . .

VW Type 3 Replacement Carburetor Linkage

I'm working on an old Volkswagen Type 3 for a friend, she's sort of an automotive foster child. The car in question is a 1972 VW Squareback named Adelaide and she is in surprisingly good shape except for her motor. Fortunately I have in my warehouse a spare Type 3 engine that was given to me by my father-in-law several years ago that will fit Adelaide perfectly.

Unfortunately, some of the parts for her carburetors needed to be fabricated.

Altoids Tin Divider and Tweezers

One of my most popular projects has been the etched Altoids tins that I made for the Steampunk Bible article I wrote. For years I've carried one in my bag that I've used for various medications and vitamin pills when traveling. I had cut up one of those typical SMTWTFS pill boxes to make the dividers and while it worked well enough it was a royal pain to get the pills out with my no-so-slender fingers.

Make:Blog 5 4 3 2 1 Things About . . .

... me!

The lovely folks over at Make:Blog asked me to answer some questions for their 5 4 3 2 1 Things About . . . series and I was more than happy to oblige!

Foundry Furnace - Final

[Updated. Click through for the details. I gotta stop saying "final iteration!" - Jake]

Here's the final iteration of my foundry furnace. I've re-built the burner to be fired with propane and waste oil rather than gasoline and waste oil. I built my oil injector based on plans from the wonderful folks over at Lionel Labs, it's essentially identical to "The Brute."

I also added a light pole. Since I have a day job, night-time is often my only opportunity for recreation of the metal melting sort.



Vintage Tomorrows - At Powell's Books Monday March 25th

Hey Portland! Don't miss futurist Brian David Johnson and cultural historian James Carrott at they explore steampunk, a cultural movement that's captivated thousands of artists, designers, makers, hackers, and writers throughout the world. The even is at Powell's Books at Cedar Hills Crossing ​on Monday, March 25th @ 7:00PM. Hey! I really like the model they got for the cover photo!

From Amazon.com:

What would today’s technology look like with Victorian-era design and materials? That’s the world steampunk envisions: a mad-inventor collection of 21st century-inspired contraptions powered by steam and driven by gears. In this book, futurist Brian David Johnson and cultural historian James Carrott explore steampunk, a cultural movement that’s captivated thousands of artists, designers, makers, hackers, and writers throughout the world.

. . .

Doctagram

Here is a thing I made.
